Shopping mall

Excellent vocal performance

Churches

1.5" HF compression driver

conference rooms

Low frequency response extend to 50Hz

background music

With CPS (Coaxial Point Source) technology

Technical Specification

Frequency Response

73Hz~18kHz(±3dB) 50Hz~20 kHz(-10dB )

Nominal directivity(-6dB)

90°(cone)

Sensitivity(@1w/1m)

89dB SPL

Power Rating

30W/15W/7.5W/3.8W(可调)

Impedance

70V-100V-8 ohm

Power Rating

30W

Transducers

LF: 8" driver HF: 1.5" drivr

Power Input

Connectors

Binding post

Speaker Cables

1+1-

Physical Data

Dimensions

270x180mm

Hole Size

245mm

Weight

3.4kg

Material

ABS plastics

Finish

White 9016

Grille

Metal grid

Installation

Ceiling-mounted
