Shopping mall

Excellent vocal performance

Churches

1.5" HF compression driver

conference rooms

Low frequency response extend to 100Hz

With CPS (Coaxial Point Source) technology

Technical Specification

Frequency Response

120~18kHz(±3dB),100Hz~20 kHz (-10 dB )

Nominal directivity(-6dB)

90°(cone)

Sensitivity(@1w/1m)

88dB SPL

Power Rating

30W/15W/7.5W/3.8W((Adjustable)

Impedance

70V-100V-8 ohm

Power Rating

30W

Transducers

LF: 6" driver HF: 1.5" driver

Power Input

Connectors

Binding post

Speaker Cables

1+1-

Physical Data

Dimensions

230 x150mm

Hole Size

200mm

Weight

2.3 kg

Material

ABS plastics

Finish

White 9016

Grille

Metal grid

Installation

Ceiling-mounted
